G7S620-N-G
Intel® 865G ATX System Board
PROCESSOR
ONBOARD AUDIO FEATURES
Realtek ALC655
•
LGA 775 socket for:
•
•
16-bit stereo full-duplex codec with 48KHz sampling rate
- Intel® Pentium® D
•
High quality differential CD input
- Intel® Pentium® 4
•
True stereo line level outputs
- Intel® Celeron D
•
S/PDIF-out interface
•
Supports Intel Enhanced Memory 64 Technology (EMT64T)
5.1-channel audio output
•
•
Supports Enhanced Intel SpeedStep Technology (EIST)
•
Supports Intel Hyper-Threading Technology
ONBOARD LAN FEATURES
•
Supports 800/533MHz FSB
• Two Realtek RTL8110SC PCI Gigabit LAN controllers
CHIPSET
• Supports 10Mbps, 100Mbps and 1Gbps data transmission
• IEEE 802.3 (10/100Mbps) and IEEE 802.3ab (1Gbps)
•
Intel® chipset
compliant
- Intel® 865G Graphics Memory Controller Hub (GMCH)
- Intel® 82801EB I/O Controller Hub (ICH5)
IDE INTERFACE
•
Supports up to UltraDMA 100Mbps hard drives
SYSTEM MEMORY
•
PIO Mode 4 Enhanced IDE (data transfer rate up to
•
Supports two channel (64-bit wide) memory interface
14MB/sec.)
- Each channel supports 2 DIMM sockets
Serial ATA INTERFACE
•
Supports up to 4GB system memory
•
Synchronous operation with processor system bus
• Supports two SATA (Serial ATA) interfaces which are
- PC2700/PC3200 (DDR333/DDR400) with 800MHz FSB
compliant with SATA 1.0 specification (1.5Gbps interface)
CPU. DDR333 will run at 320MHz memory frequency
ACCELERATED GRAPHICS PORT (A.G.P.)
when used with 800MHz FSB CPU.
•
Supports AGP 3.0 and AGP 2.0 spec.
- PC2700 (DDR333) with 533MHz FSB CPU
•
AGP 8x data rate provides a theoretical maximum
•
Supports non-ECC (x64) unbuffered DIMM using 128Mb,
bandwidth of 2.13GB/sec.
256Mb or 512Mb
•
Supports 1.5V AGP 4x with up to 1066MB/sec. band-
width for 3D graphics applications (3.3V AGP card is not
BIOS
supported)
•
Award BIOS
•
4Mbit flash memory
REAR PANEL I/O PORTS
•
1 mini-DIN-6 PS/2 mouse port
ENERGY EFFICIENT DESIGN
•
1 mini-DIN-6 PS/2 keyboard port
•
Supports ACPI specification and OS Directed Power
•
1 DB-25 parallel port
Management
•
1 DB-9 serial port
•
Supports ACPI STR (Suspend to RAM) function
•
1 DB-15 VGA port
•
Wake-On-Events include:
•
2 RJ45 LAN ports
- Wake-On-PS/2 Keyboard/Mouse
•
4 USB 2.0/1.1 ports
- Wake-On-USB Keyboard/Mouse
•
Mic-in, line-in and line-out
- Wake-On-Ring (external modem)
I/O CONNECTORS
- Wake-On-LAN
•
2
connectors for 4 additional external USB 2.0/1.1 ports
- RTC timer to power-on the system
•
3
connectors for 3 external serial ports
•
System power management supported
•
1
front audio connector for external line-out and mic-in jacks
•
CPU stopped clock control
•
1
CD-in internal audio connector
•
Microsoft® /Intel® APM 1.2 compliant
•
1
S/PDIF-out connector
•
Soft Power supported - ACPI v1.0a specification
•
1
connector for IrDA interface
•
AC power failure recovery
•
2
Serial ATA, 2 IDE and 1 floppy
•
1
Digital I/O connector
DAMAGE FREE INTELLIGENCE
•
1
Digital I/O power connector
•
Monitors CPU/system temperature
•
2
ATX power supply connectors
•
Monitors CPU/1.5V/3.3V/5V/+12V voltages
•
1
Wake-On-LAN connector
•
Monitors CPU/system fan speed
•
2
fan connectors
•
Read back capability that displays temperature, volt-
EXPANSION SLOTS
age and fan speed
•
Supports Watchdog Timer function
•
1 AGP slot
•
2 ISA slots
ONBOARD GRAPHICS FEATURES
•
4 PCI slots
•
Graphics memory
TEMPERATURE
- Shares 1MB/8MB/16MB of the system memory in DOS
• 0oC to 60oC
mode
- Uses Dynamic Video Memory Technology (DVMT) in
HUMIDITY
Windows mode
• 10% to 90%
•
Graphics controller
PCB
- Core frequency of 266MHz
- 350MHz integrated 24-bit RAMDAC
•
4 layers, ATX form factor
- Analog display up to 2048x1536 @ 60Hz refresh
•
30.5cm (12.05") x 24.4cm (9.6")
- 3D setup and render engine - Discrete, Triangles, Strips
SAFETY
and fans
• UL, cUL, FCC Class B, CE
- Per pixel perspective corrected texture mapping
- Software DVD at 30fps, full screen
•
2D graphics features
REAR PANEL I/O PORTS
- Optimized 256-bit BLT engine
- 32-bit alpha blended cursor
PS/2
- Programmable 3-color transparent cursor
LAN
LAN
Parallel
Mouse
Mic-in
•
3D graphics features
- Maximum 3D resolution: 1600x1200x32 @ 85Hz
Line-in
- Flat and Gouraud shading
- 16- and 24-bit Z-buffering and 16- and 24-bit W-buffer-
Line-out
ing
- Vertex and programmable pixel fogging and atmo-
spheric effects
PS/2
COM
VGA
USB 1-2 USB 3-4
- Double and triple render buffer
K/B
All product names mentioned are trademarks or registered trademarks of their respective companies. All specifications are
subject to change without prior notice. © 2007 DFI-ITOX, LLC.
MA-SD-146-0607
